Sizing Moisture Content Indicator

Detail

SKS-521, Sizing Moisture Content Indicator

Product Details
Used for online detection of the moisture content in various sizing machines. The indicated value on the display can be cross-referenced with a calibration chart to obtain the moisture content. When the moisture content deviates from the set process value, red and green lights provide an alarm.

Main Technical Parameters

Measurement Range

  • 1.5–14.0%

Moisture-Sensing Electrodes

  • Double Roller or Three-Roller System

Overall Dimensions

  • L250 × W150 × H300mm





    SKS-522, Automatic Yarn Count Balance

    Product Details
    Used for quickly determining the linear density of various yarns. The sample length can be set, and the instrument automatically weighs the yarn or sliver, calculates, and prints results such as AV and CV%. It can store 100 data sets, with options to delete or continue measurement. Ideal for textile mills, research institutions, and educational institutions.

    Main Technical Parameters

    Capacity and Accuracy

    • 210g, 1mg

    Display Mode

    • LCD Screen

    Weighing Pan Diameter

    • 100mm

    Overall Dimensions

    • L343 × W217 × H307mm





    SKS-523, Mechanical Yarn Tension Meter

    Product Details
    Used to measure the tension of yarns in both stationary and moving states during processes such as winding, warping, and twisting in textile engineering.

    Main Technical Parameters

    Measurement Range

    0–50 cN

    0–100 cN

    0–200 cN

    0–300 cN

    Effective Needle Angle

    270°

    Overall Dimensions

    153 × 58 × 65mm

    SKS-524, Yarn Sample Winder

    Product Details
    Designed for winding yarns onto thin paper tapes, various synthetic materials, and other suitable substrates. This machine is specifically developed for producing various sample cards.

    Ideal for the following applications:

  • Sample card preparation

  • Whiteness measurement

  • UV resistance testing

  • Sample calibration

  • Color comparison

  • Cleanliness inspection

  • Color card winding

  • UV testing

  • Main Technical Parameters

  • Winding Speed

  • 100–900 r/min (adjustable)

  • Sample Density

  • 0.01–0.99mm (adjustable)

  • Winding Plate Size

  • Determined by user requirements

  • Number of Winding Layers

  • 1–99 layers

  • Winding Width

  • 1–150mm

  • Number of Yarn Ends

  • 1–25 ends

  • Overall Dimensions

  • L810 × W400 × H400mm





    SKS-525, Yarn Dynamic Friction Coefficient Tester

    Product Details
    Used to determine the friction characteristics of yarns, applicable to synthetic filament yarns and other types of yarns for measuring dynamic friction coefficients.

    • ASTM D 3108-2001

    • ASTM D 3412-2001

    Main Technical Parameters

    Model

    • Y110

    Force Measurement Range and Accuracy

    • 0–500cN ±1%

    Friction Coefficient Range

    • 0 < μ < 1

    Adjustable Friction Angle Range

    • 0°–360°

    Pre-tension Range

    • 0–24cN

    Yarn Testing Speed

    • 0–100m/min

    Display Information

    • Speed, Pre-tension, Friction Coefficient

    Power Supply and Consumption

    • AC220V, 50Hz, 300W






      SKS-526, Yarn Length Measuring Machine

      Product Details
      Used in the textile industry for testing the yarn length, linear density (count), and yarn strength.

      Applicable Standards:

    • GB/T 4743, 14343, 6838

    • ISO 2060

    • Main Technical Parameters

    • Yarn Frame Perimeter

    • 1000 ± 1mm

    • Maximum Number of Revolutions

    • 1–9999, adjustable

    • Yarn Tension

    • 2–100cN/pic

    • Spindle Spacing

    • 65mm

    • Yarn Frame Speed

    • 30–280r/min

    • Power Supply

    • AC220V, 50Hz

    • Overall Dimensions

    • 780 × 660 × 480mm (L × W × H)




      SKS-527, Fully Automatic Single Yarn Strength Tester

      Product Details
      Used for determining the breaking strength and elongation at break of single yarns, synthetic filaments, and textured yarns. The machine features a high-precision, high-speed force measurement system, ensuring accurate test data. It is controlled by a computer via an RS232 port, providing detailed real-time and historical data, reports, and graphs, with a built-in database. It also includes an automatic data exclusion function, removing any data outside the normal strength range. The device has a self-diagnostic function, alerting the user to any malfunctions and providing fault details.

      Applicable Standards:

      • GB/T 3916, 14344, 16604

      • ISO 2062

      Main Technical Parameters

      Force Range

      • ≤5000cN ±1%

      Sample Clamping Distance

      • 100–500mm, adjustable

      Stretching Speed

      • 20–10000mm/min

      Data Input Method

      • Standard keyboard input

      Clamping Method

      • Pneumatic

      Number of Test Spools

      • 1–20 spools

      Overall Dimensions

      • Main Unit: 650 × 580 × 1730mm (L × W × H)

      Power Supply

      • AC 220V

    SKS-528, Silk Fiber Cohesion Force Tester

    Product Details
    This instrument is suitable for testing the cohesion force of silk fibers according to the national standard GB/T 1798-2008 "Silk Testing Methods." It measures the cohesion force between different strands of silk from silkworm cocoons and can also be used to test the friction fastness of synthetic fibers, yarns, and other materials.

    The silk fibers are composed of several filaments bound together by their sericin (silk gum), and their cohesion force determines how firmly the fibers hold together. Poor cohesion results in weak fiber structures, more broken fibers, lower tensile strength, and poor abrasion resistance. During weaving, weak silk easily breaks, affecting the final quality. Therefore, testing the cohesion force of silk is crucial for assessing the internal quality of the silk.

    The newly designed Silk Fiber Cohesion Force Tester uses a precise linear guide transmission system, ensuring smooth, friction-free reciprocating movement of the friction knife holder, ensuring uniform friction during testing. The instrument also features an intelligent touch screen control system for easier operation.

    Main Technical Parameters

    Friction Reciprocation Speed

    • 60–150 times/min, adjustable

    Friction Knife Holder Stroke

    • 90mm

    Tension Load

    • 180g

    Tension Weights

    • 25g (2 pieces), 30g, 50g, 50g weight tray

    DC Motor with Gearbox

    • AC220V / 80W, 1500r/min

    Overall Dimensions

    • L600 × W350 × H320mm
