#SKS-501, Comprehensive Fiber Fineness Analyzer



The Comprehensive Fiber Fineness Analyzer integrates a high-resolution industrial camera with an optical microscope, enabling seamless computer connectivity. Equipped with advanced analytical software, it performs precise measurements of fiber diameter, fineness, cross-sectional area, and hollowness while identifying the composition of fibers in blended materials.

Technical Parameters:

  1. Measuring Range: 1–200 μm

  2. Resolution: 0.01 μm

  3. Test Accuracy: ±0.1 μm

  4. Magnification Levels: 200x, 500x, 1000x, 2000x

  5. Measurement Methods:

    • Manual and automatic measurement of fiber diameter and fineness for diverse fiber types.

  6. Cross-Section Analysis:

    • Measurement of cross-sectional area and hollowness for chemical, special-shaped, and hollow fibers.

  7. Blended Fiber Analysis:

    • Identification of fiber content in blended products through longitudinal and cross-sectional morphology analysis.

  8. Data Output:

    • Automated generation of test results and detailed reports in EXCEL format with automatic data storage.

The analyzer ensures high precision and efficiency, making it an essential tool for fiber quality assessment and research.









#SKS-502,  Moisture Regain Tester

The SKS-502,  Moisture Regain Tester utilizes advanced microcomputer technology and features a liquid crystal display (LCD) for real-time moisture regain readings. Equipped with voice prompts, high resolution, and a broad measurement range, this portable device integrates the probe and host into one compact unit. It supports both single and double probe configurations, ensuring high component integration, ease of operation, and reliable accuracy. Ideal for cotton inspection in both southern and northern cotton-producing regions, the SKS-501 enhances efficiency in cotton purchase and warehouse storage assessments.

Main Technical Parameters:

  1. Model: SKS-502

  2. Moisture Regain Test Range:

    • BD-M5A: 9%–30% ±0.2%, resolution 0.1%

    • BD-M5G: 7%–30% ±0.2%, resolution 0.1%

  3. Alarm Settings:

    • Adjustable for any range within the test parameters (0.5% per gear increment).

  4. Voice Prompts:

    • Excess Moisture: “Moisture regain exceeds the standard.”

    • Low Voltage: “Please replace the battery.”

  5. Power Supply:

    • DC voltage: 6V, 9V (compatible with 4 or 6 AA dry batteries).

    • Intermittent power supply for extended battery life.

  6. Overall Dimensions:

    • 400 × 150 × 100 mm (L × W × H)

The SKS-502 delivers high-precision moisture analysis, ensuring consistency and accuracy in cotton quality assessment.





#SKS-503, Saw Gin Tester

The #SKS-503, Saw Gin Tester is designed for cotton procurement departments to test seed cotton lint content and is also suitable for research institutions to evaluate cotton varieties and establish physical grade standards for saw gin cotton. It is an ideal replacement for traditional roller gin machines, offering stable performance, easy operation, and safe use. The test results comply with national standards and cotton ginning quality indicators.

Main Technical Parameters:

  1. Model: SKS-513

  2. Saw Blade Diameter: 280 mm

  3. Seed Cotton Sample Mass: 1 kg

  4. Ginning Time: 50 ± 10 seconds

  5. Power Supply: AC 380V, 1.1 kW

  6. Overall Dimensions: 1390 × 540 × 1114 mm (L × W × H)

  7. Total Weight: 290 kg

#SKS-503 delivers precise and consistent results, making it an essential tool for cotton quality analysis and research.





#SKS-504, Flax Flexibility Tester

#SKS-504.  Flax Flexibility Tester is designed to measure the flexibility index of flax fibers. It evaluates the degree of bending at the bundle ends of flax fibers formed into bundles of specified length and mass, providing a key grading parameter for processed flax.

Main Technical Parameters:

  1. Model: SKS-504

  2. Test Sample Length: 270 mm

  3. Minimum Scale Division: 1 mm

  4. Plate Descent Time: 20 ± 2 seconds

  5. Maximum Slide Rod Stroke: 60 mm

  6. Overall Dimensions: 340 × 200 × 390 mm (L × W × H)

  7. Power Supply: AC 220V

The #SKS-504 ensures accurate and reliable assessment of flax fiber flexibility, making it an essential tool for quality control and research.

#SKS-505, Saw Gin Seed Cotton Lint Tester

#SKS-505,  Saw Gin Seed Cotton Lint Tester is designed for cotton procurement departments to assess seed cotton lint content. It is also suitable for research institutions to evaluate cotton varieties and establish physical grade standards for saw gin cotton. As an ideal alternative to traditional roller gin testers, it offers stable performance, easy operation, and safe use. The ginning results comply with national standards and cotton ginning quality indicators.

Main Technical Parameters:

  1. Model: SKS-505

  2. Saw Blade Diameter: 280 mm

  3. Seed Cotton Sample Mass: 1 kg

  4. Ginning Time: 50 ± 10 seconds

  5. Power Supply: AC 380V, 1.1 kW

  6. Overall Dimensions: 1390 × 540 × 1114 mm (L × W × H)

  7. Total Weight: 290 kg

The XJ114 ensures precise and efficient cotton lint content analysis, making it an essential tool for quality control and research applications.






#SKS-506, Flax Flexibility Tester

#SKS-506,  Flax Flexibility Tester is specifically designed to measure the flexibility index of flax fibers. This index is determined by evaluating the degree of bending at the bundle ends of flax fibers formed into bundles of specified length and mass, expressed in millimeters. The results serve as a critical indicator for determining the grade of processed flax.

Main Technical Parameters:

  1. Model: SKS-506

  2. Test Sample Length: 270 mm

  3. Minimum Scale Division: 1 mm

  4. Plate Descent Time: 20 ± 2 seconds

  5. Maximum Slide Rod Stroke: 60 mm

  6. Overall Dimensions: 340 × 200 × 390 mm (L × W × H)

  7. Power Supply: AC 220V

The #SKS-506 nsures precise and consistent evaluation of flax fiber flexibility, making it an essential tool for quality assessment and research in fiber processing.





SKS-507, Raw Cotton Impurity Analyzer

Product Details
Designed for analyzing the impurity content in raw cotton, cotton sliver, and chemical fibers, as well as detecting defects in various fibers (up to 65mm in length).

Applicable Standards:

  • GB/T 6499-86 "Test Method for Impurity Content in Raw Cotton"

  • GB/T 14339-1993 "Test Method for Defects in Synthetic Short Fibers"


Main Technical Parameters

Model

  • SKS-507

Machine Width

  • 490mm

Feeding Roller Diameter

  • Φ57.15mm, Speed: 0.9r/min

Licker-in Diameter

  • Φ238.76mm, Speed: 900r/min

Power Supply

  • AC380V / 0.75kW, 1390r/min

Overall Dimensions

  • L1020 × W715 × H875mm




    SKS-508, Chemical Fiber Fineness Analyzer

    Product Details
    This instrument uses the airflow method to measure the linear density of chemical fibers. It can quickly determine the linear density of polyester, acrylic, and viscose staple fibers with a fineness range of 1.2–6.0 dtex.


    Main Technical Parameters

  • Measurement Range

  • 1.2–6.0 dtex

  • Sample Weight

  • Polyester: 5.5g

  • Acrylic: 4.9g

  • Overall Dimensions

  • 500 × 290 × 370mm (L × W × H)

  • Viscose: 5.5g




    SKS-509, Cotton Fiber Polarization Maturity Tester

    Product Details
    Designed to determine the maturity coefficient of upland cotton and long-staple cotton.

    Applicable Standard:

    • GB/T 6099.2


    Main Technical Parameters

    Model

    • SKS-509

    Degree of Polarization

    • <8

    Testing Accuracy

    • Maturity Coefficient (M): ±0.03, LED

    Lamp Specifications

    • BA15D 15W/6V

    Selenium Light Source

    • 56-AΦ45

    Overall Dimensions

    • L300 × W400 × H100mm





      SKS-510, Cotton Fiber Photoelectric Length Tester

      Product Details
      Used to measure the length of cotton fibers.

      Applicable Standard:

    • GB/T 6098.2


    • Main Technical Parameters

      Model

    • Y146-3B

    • Measurement Range

    • 25–31mm

    • Measurement Accuracy

    • ±0.5mm

    • Sample Weight

    • 250mg (Equivalent to a photoelectric degree of 33%–40%)

    • L380 × W185 × H280mm
